VL152
2‑way fullrange cabinet
- 15" Passive 2-Way High-Power Multi-Functional 2-Way Cabinet, 500W 8 Ohms
- Rotatable CAD-optimized 90° x 45° Constant Directivity Horn
- Switchable to Biamped Mode
- 15" Neodymium DND 15400 Woofer, 1.4" Neodymium ND6 Driver
- Voice Coil Tracking Protection
- Also available in white
Todays sound reinforcement and public address applications require equipment that guarantee exceptional sound quality for a large variety of different events. Multi‑functionality is a must in order to be able to react on‑site to varying customer demands. The Dynacord VL152 2‑way fullrange cabinet has been optimized acoustically and mechanically for multi‑functional applications. With a variety of mounting accessories and decent cosmetics the VL152 is ideally suited to be used in most demanding applications.
Specifications
| Cabinet | Full-Range |
| Configuration | Passive 2-Way Switchable to biamped mode |
| Nominal impedance | 8 Ω |
Specifications | |
| Rated power RMS | 500 Watts |
| Program power | 1000 Watts |
| Peak power | 2000 Watts |
| SPL 2,83 V / 1m 1W / 8 Ω | 100 dB |
| Max. SPL 1m (calculated with peak power) | 133 dB |
| Frequency range (-10dB) Full range | 50Hz — 20kHz |
| Frequency range (-10dB) measured with H5000-RCM26 preset | 40Hz — 20kHz |
| Coverage angle 1 kHz -6dB | 90° * 45° |
| Passive crossover frequency | 1.5 kHz |
| Active crossover frequency | 1.5 kHz 24dB/Oct. Linkwitz-Riley, 1.5 kHz Linear-Phase FIR |
| Voice coil tracking protection | Yes |
| Component HIGH Order No | Electro-Voice ND6-8 Neodymium 361493 |
| Component LOW Order No. | DND15400 Neodymium 366303 |
| Connectors Full-Range | 1+, 1- |
| Wired through | 2+, 2- |
| Connectors Biamped | Lo 1+, 1- Hi 2+, 2- |
| Wired through | 1+, 1-, 2+, 2- |
| Connector model | Speakon 2x NL4 MPR |
| Dimensions (WxHxD) | 441x780x407mm (17.34" x 30.71" x 16.04") |
| Net weight | 26kg (57.31Ibs) |
| Shipping weight | 28kg (61.72Ibs) |
| Enclosure material | Birch plywood |
| Finish | Black, 2-component paint |
| Grille | Powder coated steel, acoustic foam |
| Handles | 2 |
| Warranty | 36 Months |
