Dynacord MXE5-64 Matrix Mix Engine
Matrix Mix Engine
- Open architecture DSP matrix for high performance audio applications
- 12 mic/line inputs, 8 line outputs, 8 configurable GPIOs
- 64 x 64 Dante channels
- TaskEngine for sophisticated system control and integration
- Integrated into SONICUE Sound System Software
The MXE5-64 Matrix Mix Engine is a performance audio matrix designed to deliver high-quality audio in fixed installation projects, operating at 96 kHz or 48 kHz.
Working as a control center and communications hub for other system devices and IP-based peripherals, it provides comprehensive supervision and system wide control, featuring 12 analog mic/line inputs, 8 line outputs and 64x64 Dante channels.
The freely configurable DSP unit offers a variety of DSP blocks, the configurable matrix blocks support up to 3840 cross-points and up to 256 internal signal paths for customized DSP designs. Onboard are professional input and output processing features, including mixing, parametric EQ, delays, compression, limiting, ducking, auto mixing, auto gain control, ambient noise compensation and a comprehensive speaker processing with FIR drive.
MXE’s TaskEngine provides advanced, system wide control with functions like scheduler and scene handling. The MXE5-64 is entirely designed and configured in SONICUE Sound System Software which also allows the creation of customized GUIs for use in SONICUE Control on TPC-1 touch panels, iOS devices or PCs.
产品规格
| DSP Matrix Mix Engine | Open architecture DSP, sound system manager, system control and supervision |
| Matrix Size | Flexible with 3860 cross-points, 256 signal paths |
| Dante audio (48/96 kHz) | 64 x 64 channels (64 Flows) |
| Analog Inputs | 12 mic / line w. 48V phantom power |
| Analog Outputs | 8 line |
| Control ports | 8 GPIO (digital in/out, analog in) |
Specifications | |
| Signal to Noise Ratio (A-weighted) | > 118 dB |
| THD+N | < 0.002 % |
| Sampling rate | 96 kHz / 48 kHz |
| Latency (analog in/out, 96/48 kHz) | < 0.22 ms / 0.45 ms |
| Signal Processing | 32/40-bit floating point |
| Max. input/output level | + 22 dBu |
| DSP blocks | EQs, x-over, FIR drive, compressor, PA & RMS limiter, noise gate, ducker, automatic gain control, ambient noise compensation, mix-matrix, router, auto mixer, delay, generators, detectors, VU meters, polarity, level, mute |
| TaskEngine (system logic) | Analog, logic and text operations, scheduler, scene handling, OCA & HTTP protocol |
| Safety / Redundancy | Int. supervision, system monitoring, watchdog, fault output, audio redundancy supported |
| Dimensions (w x h x d) | 483 x 43.5 x 471 mm (19”, 1RU) |
| Weight | 6.0 kg (13.2 lbs) |
Videos
Dynacord MXE5-64 Matrix Mix Engine with SONICUE 1.4
SONICUE 1.4 - First preview
SONICUE Training Series: Introduction and getting started
NEW! Dynacord MXE5 matrix mix engine Summer Showcase webinar
Introducing the Dynacord MXE5 matrix mix engine - global reveal webinar
Dynacord MXE5 – built on comprehensive software
Dynacord MXE5 – delivering the highest audio quality
Dynacord MXE5 – made for mixing and routing
Dynacord MXE5 – ready for a wide range of applications
Dynacord MXE5 #MatrixMixEngine
新闻
- Dynacord's MXE5 matrix mix engine gets new functionality for IP-based media and building control systems
- Dynacord SONICUE software and MXE5 matrix mix engine key to audio upgrade at Del Valle High School football stadium
- Third-party loudspeaker settings now available for Dynacord electronics via SONICUE software
- Dynacord MXE5 brings smart control to sound system solution in multi-purpose meeting venue
下载
Technical Documentations
| Name | Language & Download |
|---|---|
| MXE5-64 A&E specs | EN |
| Name | Language & Download |
|---|---|
| MXE5 EU Declaration of Conformity | EN |
| Name | Language & Download |
|---|---|
| Application Note MXE API with Advantech ADAM IoT gateways v1.0 | ZH EN |
| Application Note MXE Remote Control with Inter VLAN Routing and ACL | EN DE ZH |
| MXE API with Advantech ADAM IoT gateways v1.0 | ZH |
| Application Note MXE active HTTP API with Barix Barionet 50 100 v2.0 | EN |
| Application Note MXE active HTTP API with HMB-TEC DMX Ethernet Converter v2.0 | EN |
| Application Note MXE with RDL Control v2.0 | EN |
| Application Note MXE with RDL Dante | EN |
