C2800FDi
DSP 2 x 1400 W Leistungsverstärker für Festinstallationen
- DSP-Verstärker für die Festinstallation, Euroblock Anschlüsse
- Integrierte Lautsprecher-Signalverarbeitung mit FIR-Drive Technologie
- Marktführende Audioperformance, solide Bauweise und höchste Zuverlässigkeit.
- Low Z und 70V Betrieb und Energiespar-Standby-Modus
- Intuitive, einfache Konfiguration und Bedienung mit SONICUE Sound System Software (mit Firmware 2.0)
Technische Daten
| Maximum Output Power, Single Channel | 2Ω= 2300W; 2.7Ω= 2000W; 4Ω= 1400W; 8Ω= 700W; |
| Maximum Output Power, Dual Channel | Load Impedance= 2Ω=2200W; 2.7Ω=1800W; 4Ω=1300W; 8Ω=650W; High Impedance= 70V Operation=2x 1250W; 100V Operation=2x 2500W (-3.0 dB) |
| Maximum Output Power, Bridged | Load Impedance= 4Ω=4400W; 8Ω=2600W; High Impedance= Not recommended |
Technische Daten |
|
| Maximum RMS Voltage Swing, THD = 1%, 1kHz | 78.8V |
| Voltage Gain ref.1kHz | 32.0dB |
| IMD-SMPTE, 60 Hz, 7 kHz | <0.1% |
| DIM 30 | <0.05%% |
| Maximum Input Level | +21dBu |
| Crosstalk | < -80dB |
| Frequency Response | 10 Hz to 21 kHz (±1 dB) |
| Input Impedance, active balanced | 20kΩ |
| Signal-to-Noise Ratio (A-weighted) | >107dB |
| Output Noise , A-weighted | <-68dBu |
| Output Stage Topology | Class H |
| Power Requirement | 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured) |
| Power Consumption | 700W |
| Protection | Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay |
| Cooling | Front-to-rear, 3-stage-fans |
| Safety Class | I |
| Available Color | Black |
| Height | 88mm (3.46") |
| Width | 483mm (19.02") |
| Depth | 462.4mm (18.2") |
| Weight Net | 16.2kg (35.71 lbs) |
| Signal Processing | FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance |
| High Impedance Operation | 70 V, 100 V (dual channel & bridged) |
| Remote Power ON/GPIO | Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection |
| Operating Temperature Range | +5°C to +40°C (40°F to +105°F) |
| Direct Drive Load Capability | Dual Channel 70V Operation: 2 x 1250 W (0.0 dB) Dual Channel 100V Operation: 2 x 2500 W (-3.0 dB) Bridge Mode 70V Operation: Not recommended Bridge Mode 100V Operation: 1 x 1250 W (0.0 dB) |
| Remote control | SONICUE sound system software (requires firmware 2.0) |
| Total Harmonic Distortion | < 0.05% |
