L series FIR drive power amplifiers
Two-channel power amplifiers for live sound
- SONICUE 1.1. upgrade provides enhanced DSP functionality to 10-band PEQs and a dedicated array processing section
- Rock solid amplifier technology engineered in Germany
- Extremely powerful, proven audio performance
- Engineered for constant stability at 2 ohms
- Sophisticated protection circuitry always protects the amplifiers and connected loudspeakers
- High-performance, bulletproof voltage handling
- On-board DSP includes multi-band PEQs, crossovers, limiters and delay per channel
- Advanced FIR drive to optimize original factory loudspeaker settings yielding a level of unparalleled performance
- Intuitive and simplified set-up, tuning and operation with SONICUE sound system software
Dynacord's L Series power amplifiers are engineered to provide sound reinforcement for demanding live music applications. They are ideal for performing musicians and production companies providing sound reinforcement for live performances in venues like music clubs, community hall events, performance centers, and sports venues.
The L Series power amplifiers comprise a powerful linear amp design with a best in class, tour grade feature set that brings real professional performance to a new, more accessible price point. Like all Dynacord amplifiers, the L Series offers high-quality components and truly professional processing power and performance characteristics. Their engineering and applied technologies enable exceptional sound quality with plenty of headroom. Equipped with an extremely robust power supply and a powerful, linear amp design, flawless operation is guaranteed – even in the most demanding environments. A sophisticated protection circuitry ensures safe, reliable operation under all conditions.
L Series are supported by SONICUE 1.1 sound system software, elevating them to the top league of professional amplifiers. The feature-rich onboard DSP gets a boost under SONICUE with 10 band PEQs and a dedicated array processing section. L Series are also equipped with FIR drive, a premium feature you find usually only with tour grade amplifiers, yielding a level of performance unheard of at this price point. Four different models are available, with total output power ranging from 1300 W to 3600 W at 4 ohms.
Models
 |
 |
 |
 | |
L1300FD |
L1800FD |
L2800FD |
L3600FD | |
| Load Impedance | 2Ω 2.6Ω 4Ω 8Ω | 2Ω 2.6Ω 4Ω 8Ω | 2Ω 2.7Ω 4Ω 8Ω | 2Ω 2.7Ω 4Ω 8Ω |
| Maximum Output Power, SIngle Channel | 2Ω=1100W; 2.6Ω=950W; 4Ω=660W; 8Ω=350W | 2Ω= 1600W; 2.6Ω= 1300W; 4Ω= 950W; 8Ω= 480W | 2Ω= 2300W; 2.7Ω= 2000W; 4Ω= 1400W; 8Ω= 700W; | 2Ω= 3200W; 2.7Ω= 2700W; 4Ω= 1800W; 8Ω= 950W |
| Maximum Output Power, Dual Channel | 2Ω=1000W; 2.6Ω=850W; 4Ω=600W; 8Ω=320W | 2Ω= 1400W; 2.6Ω= 1200W; 4Ω= 850W; 8Ω= 450W | 2Ω= 2200W; 2.7Ω= 1800W; 4Ω= 1300W; 8Ω= 650W; | 2Ω= 3000W; 2.7Ω= 2500W; 4Ω= 1700W; 8Ω= 900W |
| Maximum Output Power, Bridged | 4Ω=2000W; 8Ω=1200W | 4Ω= 2800W; 8Ω= 1700W | 4Ω= 4400W; 8Ω= 2600W; | 4Ω= 6000W; 8Ω= 3400W |
| Maximum RMS Voltage Swing, THD = 1%, 1kHz | 55.3 V | 65.1V | 78.8V | 90.6V |
| Voltage Gain ref.1kHz | 32.0dB | 32.0dB | 32.0dB | 32.0dB |
| IMD-SMPTE, 60 Hz, 7 kHz | < 0.1% | <0.1% | <0.1% | <0.1% |
| DIM 30 | < 0.05% () | <0.05% () | <0.05% () | <0.05% () |
| Maximum Input Level | +21 dBu | +21dBu | +21 dBu | +21dBu |
| Crosstalk | < -80dB () | < -80dB () | < -80dB () | < -80dB () |
| Frequency Response | 10 Hz to 21 kHz (±1 dB) | 10 Hz to 21 kHz (±1 dB) | 10 Hz to 21 kHz (±1 dB) | 10 Hz to 21 kHz (±1 dB) |
| Input Impedance, active balanced | 20kΩ | 20kΩ | 20kΩ | 20kΩ |
| Signal-to-Noise Ratio (A-weighted) | >104dB | >105dB | >107dB | >109dB |
| Output Noise , A-weighted | < -68 dBu | <-68dBu | < -68dBu | <-68dBu |
| Output Stage Topology | Class AB | Class AB | Class H | Class H |
| Power Requirement | 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured) | 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured) | 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured) | 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured) |
| Power Consumption | 550 W () | 700W () | 700W () | 850 W () |
| Protection | Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay | Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay | Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay | Audio limiters, high temperature, DC, HF; Back-EMF, Peak current limiters, Inrush current; limiters, Turn on delay |
| Cooling | Front-to-rear, 3-stage-fans | Front-to-rear, 3-stage-fans | Front-to-rear, 3-stage-fans | Front-to-rear, 3-stage-fans |
| Safety Class | I | I | I | I |
| Available Color | Black | Black | Black | Black |
| Height | 3.46" (88mm) | 3.46" (88mm) | 3.46" (88mm) | 3.46" (88mm) |
| Width | 19.02" (483mm) | 19.02" (483mm) | 19.02" (483mm) | 19.02" (483mm) |
| Depth | 18.2" (462.4mm) | 18.2" (462.4mm) | 18.2" (462.4mm) | 18.2" (462.4mm) |
| Weight Net | 28.44lbs (12.9kg) | 33.51lbs (15.2kg) | 35.71lbs (16.2kg) | 40.12lbs (18.2kg) |
| Signal Processing | FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance | FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance | FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance | FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance |
| Remote control | SONICUE sound system software (requires firmware 2.0) | SONICUE sound system software (requires firmware 2.0) | SONICUE sound system software (requires firmware 2.0) | SONICUE sound system software (requires firmware 2.0) |
| Operating Temperature Range | +5°C to +40°C (40°F to +105°F) | +5°C to +40°C (40°F to +105°F) | +5°C to +40°C (40°F to +105°F) | +5°C to +40°C (40°F to +105°F) |
| Mains Fuse | 240 V/230 V= T10AH; 120 V/100 V= T20AH | 240 V/230 V= T10AH; 120 V/100 V= T20AH | 240 V/230 V= T10AH; 120 V/100 V= T20AH | 240 V/230 V= T10AH; 120 V/100 V= T20AH |
| Total Harmonic Distortion | < 0.05% () | <0.05% () | <0.05% () | <0.05% () |
| Learn More | Learn More | Learn More | Learn More |
Show more specs
