Maximum Output Power, Single Channel

2Ω=1100W; 2.6Ω= 950W; 4Ω= 660W; 8Ω= 350W (Load Impedance) High impedance = 70V Operation = 1 x 625W (Bridge Mode)

Maximum Output Power, Dual Channel

2Ω=1000W; 2.6Ω= 850W; 4Ω= 600W; 8Ω= 320W (Load Impedance)

Maximum Output Power, Bridged

High Impedance= 2Ω & 2.6Ω=1x 600W; Load Impedance= 4Ω=2000W; 8Ω=1200W;

Maximum RMS Voltage Swing, THD = 1%, 1kHz

55.3V

Voltage Gain ref.1kHz

32.0dB

IMD-SMPTE, 60 Hz, 7 kHz

< 0.1%

DIM 30

< 0.05

Maximum Input Level

+21 dBu

Crosstalk

-80

Frequency Response

10 Hz to 21 kHz (±1 dB)

Input Impedance, active balanced

20kΩ

Signal-to-Noise Ratio (A-weighted)

>104

Output Noise , A-weighted

< -68dBu

Output Stage Topology

Class AB

Power Requirement

240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)

Power Consumption

550 W

Protection

Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay

Cooling

Front-to-rear, 3-stage-fans

Safety Class

I

Available Color

Black

Height

88

Width

483

Depth

462.4

Weight Net

12.9

Signal Processing

FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance

Remote control

SONICUE sound system software (requires firmware 2.0)

High Impedance Operation

70V (in bridged mode)

Remote Power ON/GPIO

Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection

Direct Drive Load Capability

Dual Channel: Not Available Bridge Mode 70V Operatoin: 1 x 625 w (0.0 dB) Bridge Mode 100V Operation: Not Available

Total Harmonic Distortion

< 0.05

Operating Temperature Range

+5°C to +40°C (40°F to +105°F)

Maximum Output Power, Single Channel

2Ω=1600W; 2.6Ω= 1300W; 4Ω= 950W 8Ω= 480W

Maximum Output Power, Dual Channel

Load Impedance= 2Ω=1400W; 2.6Ω=1200W; 4Ω=850W; 8Ω=450W; High Impedance= 70V Operation=2x 2500W (-1.5 dB);

Maximum Output Power, Bridged

Load Impedance= 4Ω=2800W; 8Ω=1700W; 100V Operation=1x 1250W

Maximum RMS Voltage Swing, THD = 1%, 1kHz

65.1V

Voltage Gain ref.1kHz

32.0dB

IMD-SMPTE, 60 Hz, 7 kHz

<0.1%

DIM 30

<0.05

Maximum Input Level

+21dBu

Crosstalk

-80

Frequency Response

10 Hz to 21 kHz (±1 dB)

Input Impedance, active balanced

20kΩ

Signal-to-Noise Ratio (A-weighted)

>105

Output Noise , A-weighted

<-68dBu

Output Stage Topology

Class AB

Power Requirement

240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)

Power Consumption

700W

Protection

Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay

Cooling

Front-to-rear, 3-stage-fans

Safety Class

I

Available Color

Black

Height

88

Width

483

Depth

462.4

Weight Net

15.2

Signal Processing

FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance

High Impedance Operation

70 V (dual channel), 100 V (bridged)

Remote control

SONICUE sound system software (requires firmware 2.0)

Remote Power ON/GPIO

Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection

Direct Drive Load Capability

Dual Channel 70V Operation: 2 x 1250 W (-1.5 dB) Dual Channel 100V Operation: Not available Bridge Mode 70V Operation: Not recommended Bridge Mode 100V Operation: 2 x 1250 W (-1.5 dB)

Total Harmonic Distortion

<0.05

Operating Temperature Range

+5°C to +40°C (40°F to +105°F)

Maximum Output Power, Single Channel

2Ω= 2300W; 2.7Ω= 2000W; 4Ω= 1400W; 8Ω= 700W;

Maximum Output Power, Dual Channel

Load Impedance= 2Ω=2200W; 2.7Ω=1800W; 4Ω=1300W; 8Ω=650W; High Impedance= 70V Operation=2x 1250W; 100V Operation=2x 2500W (-3.0 dB)

Maximum Output Power, Bridged

Load Impedance= 4Ω=4400W; 8Ω=2600W; High Impedance= Not recommended

Maximum RMS Voltage Swing, THD = 1%, 1kHz

78.8V

Voltage Gain ref.1kHz

32.0dB

IMD-SMPTE, 60 Hz, 7 kHz

<0.1%

DIM 30

<0.05%

Maximum Input Level

+21dBu

Crosstalk

-80

Frequency Response

10 Hz to 21 kHz (±1 dB)

Input Impedance, active balanced

20kΩ

Signal-to-Noise Ratio (A-weighted)

>107

Output Noise , A-weighted

<-68dBu

Output Stage Topology

Class H

Power Requirement

240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)

Power Consumption

700W

Protection

Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay

Cooling

Front-to-rear, 3-stage-fans

Safety Class

I

Available Color

Black

Height

88

Width

483

Depth

462.4

Weight Net

16.2

Signal Processing

FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance

High Impedance Operation

70 V, 100 V (dual channel & bridged)

Remote Power ON/GPIO

Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection

Direct Drive Load Capability

Dual Channel 70V Operation: 2 x 1250 W (0.0 dB) Dual Channel 100V Operation: 2 x 2500 W (-3.0 dB) Bridge Mode 70V Operation: Not recommended Bridge Mode 100V Operation: 1 x 1250 W (0.0 dB)

Total Harmonic Distortion

< 0.05

Operating Temperature Range

+5°C to +40°C (40°F to +105°F)

Remote control

SONICUE sound system software (requires firmware 2.0)

Maximum Output Power, Single Channel

2Ω= 3200W; 2.7Ω= 2700W; 4Ω= 1800W; 8Ω= 950W

Maximum Output Power, Dual Channel

Load Impedance= 2Ω=3000W; 2.7Ω=2500W; 4Ω=1700W; 8Ω=900W; 100 V Operation=2 x 2500 W

Maximum Output Power, Bridged

Load Impedance= 4Ω=6000 W; 8Ω=3400 W; High Impedance= Not Recommended

Maximum RMS Voltage Swing, THD = 1%, 1kHz

90.6V

Voltage Gain ref.1kHz

32.0dB

IMD-SMPTE, 60 Hz, 7 kHz

<0.1%

DIM 30

<0.05

Maximum Input Level

+21 dBu

Crosstalk

-80

Frequency Response

10 Hz to 21 kHz (±1 dB)

Input Impedance, active balanced

20kΩ

Signal-to-Noise Ratio (A-weighted)

>109

Output Noise , A-weighted

<-68dBu

Output Stage Topology

Class H

Power Requirement

240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)

Power Consumption

850 W

Protection

Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay

Cooling

Front-to-rear, 3-stage-fans

Safety Class

I

Available Color

Black

Height

88

Width

483

Depth

462.4

Weight Net

18.2

Signal Processing

FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance

High Impedance Operation

70V Operation & 100V Operation

Direct Drive Load Capability

Dual Channel 70V Operation: Not recommended Dual Channel 100V Operation: 2 x 2500 W (-1.5 dB) Bridge Mode: Not recommended

Total Harmonic Distortion

<0.05

Operating Temperature Range

+5°C to +40°C (40°F to +105°F)

Remote control

SONICUE sound system software (requires firmware 2.0)

Maximum Output Power, Single Channel @ 2Ω

450

Channels

2

Maximum Output Power, Single Channel @ 2Ω

600

Channels

2

Maximum Output Power, Single Channel @ 2Ω

900

Channels

2

Maximum Output Power, Single Channel @ 2Ω

1200

Channels

2

Voltage Gain, ref. 1 kHz

32,0dB - 36,0dB

Max. Input Level

+22dBu (9,76Vrms)

Frequency Response, ref 1 kHz, 8 Ω Load

15Hz…30kHz (±1dB)

Output Stage Topology

Class D

Weight Net

11.1

Channels

4

Dimensions

483 x 88.1 x 420.8 mm

Input Sensitivity, Rated Output Power @ 4 Ω, 1 kHz

1.1V (+3.0dBu)

Max. Bridged Output Power, THD = 1%, 1 kHz

1000W

Maximum Midband Output Power, 1 kHz, THD = 1%, 4 Channels at 2Ω

500W

Maximum Output Power, Single Channel @ 2Ω

1000

Voltage Gain, ref. 1 kHz

32,0dB - 36,0dB

Max. Input Level

+22dBu (9,76Vrms)

Frequency Response, ref. 1 kHz, 8 Ω Load

15Hz…30kHz (±1dB)

Output Stage Topology

Class D

Weight Net

11.1

Max. Bridged Output Power, THD = 1%, 1 kHz

2000W

Max. Midband Output Power, THD = 1%, 1 kHz, 4 Channels driven

900W

Channels

4

Dimensions

483 x 88.1 x 420.8 mm

Input Sensitivity, Rated Output Power @ 4 Ω, 1 kHz

1.55V (+6.0dBu)

Maximum Output Power, Single Channel @ 2Ω

500

Voltage Gain, ref. 1 kHz

32,0dB - 36,0dB

Max. Input Level

+22dBu (9,76Vrms)

Frequency Response, ref. 1 kHz, 8 Ω Load

15Hz…30kHz (±1dB)

Output Stage Topology

Class D

Weight Net

13.9

Channels

8

Dimensions

483 x 88.1 x 420.8 mm

Input Sensitivity, Rated Output Power @ 4 Ω, 1 kHz

32dB (1.1V (+3.0 dBu)

Max. Bridged Output Power, THD = 1%, 1 kHz

1000W

Max. Midband Output Power, THD = 1%, 1 kHz, 4 Channels driven

500W
