PROMATRIX Public address

Height

166

Width

200

Depth

66

Weight Net

0.6

Supply Voltage

15-58 VDC

Display

Black-lit LC display (122 x 32 pixels)

Part Number

PMX-15ECS

Indicator Lights

Power (green), Fault (yellow), Alarm (red)

DCS 400

19" Frame for DCS module

DCS 408R

Line relay module

DCS 409

AF relay module

DCS 409R

AF relay module

DCS 412R

Plug, 15-pin (Phoenix MC 1.5/15-STF-3.81 - 1827839)

DCS 416R

Analogue input / output module

THD+N

<0.003%

Crosstalk

-100

Frequency Response

20–20,000Hz (-0.5dB)

Input Impedance

Input A (MIC / LINE): 2.5㏀; Input B (LINE): 20㏀; Input C (PCA BUS): 20㏀

Signal-to-Noise Ratio (A-weighted)

109

Height

27.3

Width

81.8

Depth

189.3

Weight Net

0.1

AD-conversion

24bit, sigma-delta, 128 times oversampling

Audio Input

2x 3-pin Euroblock connectors, electronically symmetrical

Common mode rejection

>80dB (f=1kHz)

Input level (nominal)

+6dBu/1.55V

Input level (max before clip)

Input A (MIC / LINE): +18 dBu/6.15 V; Input B (LINE): +18 dBu/6.15 V; Input C (PCA BUS): +12 dBu/3.1 V

Sample Rate

48kHz

PCA Input

Integrated power – CAN – audio interface, RJ-45

Data Format

24-bit linear A/D conversion, 48-bit processing

SMPTE (DIN 4:1)

<0.005% (at Ue = +6dBu)

Phantom Power

+48V/10mA, switchable for input A

Supply Voltage

+3.3VDC, ± 0.3V / 6mA; +5VDC, ±0.3V / 18mA; +18VDC, ±0.5V / 66mA; -18 V DC, ± 0.5 V / 12 mA; +24 V DC/max. 1 A, depends on number of connected DPCs; +48 V DC, ± 0.5 V / 11 mA

Operating Temperature Range

5°C to +45°C
